Triumph STREET TRIPLE User Manual

139
Maintenance and Adjustment
Detach the wire retainer from its clip (do not
remove the screw) then remove the bulb
from the light unit.
1. Headlight bulb
2. Bulb clip
3. Position lamp bulb
To remove the position lamp bulb:
Without pulling the wires, ease the bulb
holder from its socket. The bulb is removed
from its holder by pulling gently upwards.
Installation for both bulbs is the reverse of the
removal procedure.
Tighten the headlamp fasteners to 27 lbf-in
(3 Nm).
Direction Turn Signal Lights
Bulb Replacement
1. I n d i c a t o r l e n s
2. Securing screw
The lens on each turn signal light is held in
place by a securing screw located in the lens
of the light.
Release the screw and remove the lens to
gain access to the bulb for replacement.
Caution
When reconnecting the battery, connect
the positive (red) lead first.
cgfn_1
2
1
3
celc_1
1
2

Triumph STREET TRIPLE Specifications

General

Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Displacement	765 cc
Transmission	6-speed
Max Torque	80 Nm (59 lbft) @ 9, 500 rpm
Front Suspension	Showa 41mm upside-down separate function big piston forks
Rear Suspension	Showa monoshock, adjustable preload and rebound damping
Front Brakes	Twin 310mm floating discs, Brembo M4.32 4-piston radial monobloc calipers, ABS
Rear Brakes	Single 220mm disc, Brembo single-piston sliding caliper, ABS
Wet Weight	188 kg
