Triumph STREET TRIPLE User Manual

99
Maintenance and Adjustment
Inspection
Check that the throttle opens smoothly,
without undue force and that it closes without
sticking. Have your authorized Triumph
dealer check the throttle system if a problem
is detected or any doubt exists.
Check that there is 0.08 - 0.12 in (2 - 3 mm)
of throttle grip free play when lightly turning
the throttle grip back and forth.
If there is an incorrect amount of free play,
Triumph recommends that you have
adjustments made by your authorized
Triumph dealer. However, in an emergency,
throttle adjustment may be made as follows:
Adjustment
1. Opening cable
2. Rubber cover
3. Opening cable adjuster
4. Lock nut
5. Opening cable – free play
measurement point
Warning
Always be alert for changes in the 'feel' of
the throttle and have the throttle system
checked by an authorized Triumph dealer
if any changes are detected. Changes can
be due to wear in the mechanism, which
could lead to a sticking throttle.
An incorrectly adjusted, sticking or stuck
throttle will lead to loss of motorcycle
control and an accident.
Warning
Use of the motorcycle with incorrectly
adjusted, incorrectly routed, sticking or
damaged throttle cables will interfere with
the throttle function resulting in loss of
motorcycle control and an accident.
To avoid incorrect adjustment, incorrect
routing, or continued use of a sticking or
damaged throttle, always have your
throttle checked and adjusted by your
authorized Triumph dealer.
4
3
2
1
5
chrv_2

Triumph STREET TRIPLE Specifications

General

Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Displacement	765 cc
Transmission	6-speed
Max Torque	80 Nm (59 lbft) @ 9, 500 rpm
Front Suspension	Showa 41mm upside-down separate function big piston forks
Rear Suspension	Showa monoshock, adjustable preload and rebound damping
Front Brakes	Twin 310mm floating discs, Brembo M4.32 4-piston radial monobloc calipers, ABS
Rear Brakes	Single 220mm disc, Brembo single-piston sliding caliper, ABS
Wet Weight	188 kg
