Triumph STREET TRIPLE User Manual

26
General Information
Instrument Panel Layout - Street Triple and Street Triple R
1. C l o c k
2. Service interval indicator
3. Speedometer
4. Stop watch icon
5. Fuel gauge
6. Engine management malfunction
indicator light
7. Left hand direction turn signal light
8. ABS warning light (ABS models only)
9. Gear shift lights
10. Tire pressure warning light (if Tire
Pressure Monitoring System (TPMS)
is fitted)
11. Tachometer 'red zone'
12. Right hand direction turn signal light
13. Neutral indicator light
14. High beam indicator light
15. Low fuel level indicator light
16. Alarm/immobilizer status indicator
light (alarm is an accessory fit)
17. Ta c h o m e t e r
18. High coolant temperature warning
light
19. Low oil pressure warning light
20. Tire pressure display (if Tire Pressure
Monitoring System (TPMS) is fitted)
21. Display screen
22. Gear position indicator
23. Coolant temperature display
24. Button B
25. Button A
2223 21 20 19 18 16 15 14
2 4 5 6 7
9
8
10
11
1
17
3
12
13
24
25

Triumph STREET TRIPLE Specifications

General

Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Displacement	765 cc
Transmission	6-speed
Max Torque	80 Nm (59 lbft) @ 9, 500 rpm
Front Suspension	Showa 41mm upside-down separate function big piston forks
Rear Suspension	Showa monoshock, adjustable preload and rebound damping
Front Brakes	Twin 310mm floating discs, Brembo M4.32 4-piston radial monobloc calipers, ABS
Rear Brakes	Single 220mm disc, Brembo single-piston sliding caliper, ABS
Wet Weight	188 kg
