Triumph STREET TRIPLE User Manual

35
General Information
TPMS Sensor ID Number
An ID number for each tire pressure sensor is
printed on a label which is on the sensor. This
number may be required by the dealer for
service or diagnostics.
If the TPMS has been fitted at the factory,
labels identifying the front and rear TPMS
sensor ID numbers will be affixed to the
spaces below.
If the TPMS is being fitted to the motorcycle
as an accessory, ensure that the dealer
records the front and rear TPMS sensor ID
numbers in the spaces provided.
System Display
1. TPMS symbol
2. Tire pressure display
3. Front tire, identified
4. Rear tire, identified
To access the tire pressure display, turn the
ignition to the ON position.
Press and release button 'A' until psi or bAr is
visible in the display screen.
Press and release button 'B' to select the front
or rear tire pressure.
When the tire pressure monitoring system
has been selected, —— psi or bAr will be
visible in the display screen until the
motorcycle is travelling at a speed greater
than 12 mph (20 km/h) and the tire pressure
signal is received.
To exit the tire pressure display, press and
release button 'A' to the desired display.
Models without TPMS: Press button 'B'
and do not touch buttons 'A' or 'B' again until
UnitS is visible in the display screen. When
UnitS is visible in the display screen, press
and release button 'A' until rEturn is visible
then press button 'B'. Trip 1 will be visible in
the display screen.
Front
Sensor
Rear
Sensor
4
3
2
1

Triumph STREET TRIPLE Specifications

General

Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Displacement	765 cc
Transmission	6-speed
Max Torque	80 Nm (59 lbft) @ 9, 500 rpm
Front Suspension	Showa 41mm upside-down separate function big piston forks
Rear Suspension	Showa monoshock, adjustable preload and rebound damping
Front Brakes	Twin 310mm floating discs, Brembo M4.32 4-piston radial monobloc calipers, ABS
Rear Brakes	Single 220mm disc, Brembo single-piston sliding caliper, ABS
Wet Weight	188 kg
