Triumph STREET TRIPLE User Manual

38
General Information
Once both hours and minutes are correctly
set, press button 'B' to confirm and t-SEt will
be visible in the display screen. Press and
release button 'A' until rEturn is visible then
press button 'B'. Trip 1 will be visible in the
display screen.
1. C l o c k d i s p l a y
2. Hours read-out
3. Minutes read-out
4. Display screen (Hour selected for
adjustment)
5. Button A
6. Button B
Service Interval Indicator
1. Service indicator
2. Remaining distance
When the ignition is switched on and the
distance to the next service is 500 miles
(800 km) or less, the service symbol will be
displayed for 3 seconds and the clock will
show the distance remaining before the next
service.
When the remaining distance is 0 miles
(0 km) the service symbol will remain on until
the service has been carried out and the
system has been reset by your authorized
Triumph dealer. If the service is overdue, the
distance will be displayed as a negative
number.
5
cfiq
2
3
4
1
6
2
1

Triumph STREET TRIPLE Specifications

General

Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Displacement	765 cc
Transmission	6-speed
Max Torque	80 Nm (59 lbft) @ 9, 500 rpm
Front Suspension	Showa 41mm upside-down separate function big piston forks
Rear Suspension	Showa monoshock, adjustable preload and rebound damping
Front Brakes	Twin 310mm floating discs, Brembo M4.32 4-piston radial monobloc calipers, ABS
Rear Brakes	Single 220mm disc, Brembo single-piston sliding caliper, ABS
Wet Weight	188 kg
