Triumph STREET TRIPLE User Manual

54
General Information
Brake Lever Adjuster -
Daytona 675 R
1. Brake lever
2. Adjusting screw
To adjust the brake lever, push the lever
forward and turn the adjusting screw
counter-clockwise as viewed from the riding
position to increase the distance, or clockwise
to shorten the distance from the handlebar.
Right Handlebar Switches
1. Engine stop switch
2. Starter button
Engine Stop Switch
In addition to the ignition switch being turned
to the ON position, the engine stop switch
must be in the RUN position for the
motorcycle to operate.
The engine stop switch is for emergency use.
If an emergency arises which requires the
engine to be stopped, move the engine stop
switch to the STOP position.
Note:
• Although the engine stop switch
stops the engine, it does not turn off
all the electrical circuits and may
cause difficulty in restarting the
engine due to a discharged battery.
Ordinarily, only the ignition switch
should be used to stop the engine.
Warning
For any model, do not attempt to adjust
the lever with the motorcycle in motion as
this may lead to loss of motorcycle control
and an accident.
After adjusting the lever, operate the
motorcycle in an area free from traffic to
gain familiarity with the new lever setting.
Do not loan your motorcycle to anyone as
they may change the lever setting from the
one you are familiar with causing loss of
control and an accident.
cgnc
1
2
chrm
1
2

Triumph STREET TRIPLE Specifications

General

Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Displacement	765 cc
Transmission	6-speed
Max Torque	80 Nm (59 lbft) @ 9, 500 rpm
Front Suspension	Showa 41mm upside-down separate function big piston forks
Rear Suspension	Showa monoshock, adjustable preload and rebound damping
Front Brakes	Twin 310mm floating discs, Brembo M4.32 4-piston radial monobloc calipers, ABS
Rear Brakes	Single 220mm disc, Brembo single-piston sliding caliper, ABS
Wet Weight	188 kg
