Parts Identification
15
PARTS IDENTIFICATION
Tiger XRX (continued)
16. Rear light
17. Rear brake fluid reservoir
18. Oil filler cap
19. Mirror
20. Headlight adjuster
21. Windscreen
22. Coolant expansion tank
23. Front fork
24. Radiator/Coolant pressure cap
25. Clutch cable
26. Engine oil level sight glass
27. Rear brake pedal
28. Rear suspension spring preload
adjuster
29. Rear brake caliper
30. Rear brake disc
31. Rear direction indicator
17 18 19 20 21 22
28
27 26 25 2430 29
16
23
31
