Parts Identification
16
Tiger XCX
1. Headlight
2. Front direction indicator
3. Electrical accessory socket
4. Fuel tank and fuel filler cap
5. Battery and fuse boxes
6. Tool kit/Accessory U-lock storage
location
7. S e a t l o c k
8. Rear wheel adjuster
9. Electrical auxiliary socket
10. Drive chain
11. Centre stand
12. Side stand
13. Gear change pedal
14. Front brake caliper
15. Front brake disc
