Trojan A - Page 20

 


16
11
10 13
12 15
14
Remove o-rings
and sleeve bolt
from sleeve.
Reinstall sleeve bolt
with 2 new o-rings.
Screw lamp into sleeve hand-tight.
Caution: Over tightening will break the
sleeve.
1
2
1
2
Hold sleeve bolt with one hand. Use other
hand to unscrew lamp from sleeve by
holding lamp tab.
Lamp
tab
Sleeve
bolt
2
1
Make sure lamp/sleeve
assembly is centered.
Caution: Over tightening
will break the sleeve.
For Basic models,
.
20
