NOTE: LABEL SETS OFF ROLL
ON LEFT SIDE, AS SHOWN
TROJAN TECHNOLOGIES
3020 GORE ROAD
LONDON, ONTARIO, CANADA
N5V 4T7
T: 519.457.3400
F: 519.457.3030
www.trojanuv.com
120-240 VAC, 50-60Hz, 1A
SERIAL #: 000001
PART #: "B"
REPLACEMENT LAMP: "C"
LAMPE DE RECHANGE: "C"
DATE OF MANUFACTURE:
MODEL:
"A"
DATE OF MANUFACTURE:
SERIAL #: 000001
PART #: "B"
UV STERILIZER
98HA
MODEL
:
"A"
REPLACEMENT LAMP: "C"
LAMPE DE RECHANGE: "C"
7 24084 XXXXX Y
MODEL
:
"A"
NOTE:
LABEL TO BE PRINTED ON 602919 LABEL STOCK.
1.
SEE SHEET 2 DESIGN TABLE FOR "A", "B", "C" AND "SYSTEM DESCRIPTION".
2.
SERIAL NUMBER "000001" IS AN EXAMPLE OF THE FIRST SERIAL NUMBER OF THIS TYPE OF SYSTEM. THE
3.
NUMBER WILL INCREASE FOR EACH ADDITIONAL SYSTEM PRODUCED. LABEL VISION WILL
AUTOMATICALLY INCREASE THIS NUMBER BY 1 FOR EACH LABEL PRINTED.
INFORMATION IS PRINTED ON THE LABEL BY A THERMAL TRANSFER PROCESS USING A ZEBRA THERMAL
4.
TRANSFER PRINTER AND LABEL VISION SOFTWARE. EXACT LOCATION OF TEXT AND IMAGES IS NOT
DEFINED. APPROXIMATE POSITIONING AS PER THE BELOW IMAGE IS ACCEPTABLE. EXACT FONT TYPES
NOT DEFINED. APPROXIMATED FONT TYPES, SIZE, WIDTH, AND SPACING AS PER THE BELOW IMAGE IS
ACCEPTABLE.
"XXXXX" IS THE LAST 5 DIGIT OF TROJAN SYSTEM PART NUMBER, AND "Y" IS CHECK SUM WHICH IS
5.
AUTOMATICALLY GENERATED BY THE LABEL VISION SOFTWARE.
SEE NOTE 5
"SYSTEM DESCRIPTION"
120-240 VAC, 50-60Hz, 1A
"SYSTEM DESCRIPTION"
SERIAL #: 000001
PART #: "B"
"SYSTEM DESCRIPTION"
120-240VAC, 50-60Hz, 1A
MAX
TM
MAX
TM
MAX
TM
"UL" OR "CE"
SEE DESIGN TABLE
(2 PL'S)
UV STERILIZER
98HA
ITEM NO
QTY.
ITEM DESCRIPTION
PART NO.
DRAWING NO.
1 1
LABEL, BLANK 3-PART UVMAX GEN2
602919 602919
CHK BY
REV BY
LOG NO.
REVISION DESCRIPTION
REV
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.5M-1994
DIMENSIONS ARE IN INCHES
TOLERANCES APPLY AS SHOWN BELOW:
REMOVE ALL BURRS, ALL CORNERS R 0.010" OR
BREAK EDGE. CRITICAL CHARACTERISTIC
REV
A
DWG NO.
603038G
DESCRIPTION
LABEL, SYSTEM UVMAX GEN1 4"OD
SCALE: 1:1
SHEET 1 OF 2
SIZE B
N/A
N/A
N/A
A
B
C
1
2
4
5
6
A
B
C
D
6
5
4
3
2
1
HISTORY:
THIRD ANGLE PROJECTION
COPYRIGHT 2008 BY TROJAN
TECHNOLOGIES. ALL RIGHTS
RESERVED. NO PART OF THIS DOCUMENT
MAY BE REPRODUCED, STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED
IN ANY FORM, WITHOUT THE WRITTEN
PERMISSION OF
TROJAN TECHNOLOGIES.
