Trojan ELITE 3000 User Manual

9
10396
No. Description Qty
47 Square End Cap 2
48 Carriage Bolt (M1O x 35) 1
49 Square Fixer (22 x 22 x 2.0) 2
50 Knob (M10) 1
51 Seat Height Adjustable Knob (M16) 1
52 End Cap for Front Stabiliser 1
53 End Cap for Front Stabiliser 1
54 End Cap for Rear Stabiliser 2
55 Pressure Wheel 1
56 Spring (ø3.2 x 55) 1
57 Seat Post Plastic Bushing 1
58 Flat Washer (ø8 x ø20 x 1.5) 8
59 Cap Nut (M8) 2
60 Carriage Bolt (M8 x 55) 2
No. Description Qty
61 Hexagon Bolt (M8 x 55) 2
62 Hexagon Bolt (M8 x 15) 6
63 Hexagon Bolt (M8 x 20) 1
64 Curve Washer (ø20 x ø8 x 1.5) 4
65 Nylon Nut (M8) 5
66 Flat Washer (ø8 x ø20 x 1.5) 3
67 Phillips Tapping Screw (ST4.2 x 25) 7
68 Phillips Self Tapping Screw (ST4.2 x 25) 6
69 Phillips Tapping Screw (ST2.9 x 12) 2
70 Sensor Wire (L = 650 mm) 1
71 Transformer (L = 2000 mm) 1
72 Handlebar Decorative Cover 1
73 Bushing (ø12 x ø8 × L30) 1
74 Handlebar Adjustable Knob (M8 × 55) 1
PARTS LIST

Trojan ELITE 3000 Specifications

General

Brand	Trojan
Model	ELITE 3000
Category	Exercise Bike
Language	English
