Trojan ELITE 3000 User Manual

8
10396
PARTS LIST
No. Description Qty
1 Main Frame 1
2 Handlebar 1
3 Handlebar Post 1
4 Rear Stabiliser 1
5 Seat Post 1
6 Front Stabiliser 1
7 Seat Slider 1
8 Pressure Plate 1
9 Magnetic Wheel Axle 1
10 Belt Pulley (ø260) 1
11 Magnetic Wheel (ø240) 1
12 Eyebolt (M6x40) 2
13 Tension Bracket 2
14 Spring Washer (ø6) 6
15 Nut (M6) 2
16 Flange Nut (M10 x 1.0) 2
17 Hexagon Bolt (M6 x 20) 4
18 Nylon Nut (M6) 4
19 Ring (ø17) 2
20 Curve Washer (ø17) 1
21 Bearing (6003Z) 2
22 Crank Cover 2
23 Left Crank (6.5”) 1
No. Description Qty
24 Right Crank (6.5”) 1
25 Flange Nut (M10 x 1.25) 2
26 Crank Cover 2
27 Left Foot Pedal (1/2”) 1
28 Right Foot Pedal (1/2”) 1
29 Left Chain Cover 1
30 Right Chain Cover 1
31 Turn Table 2
32 Belt (PJ6 / 450) 1
33 Motor 1
34 Phillips Self Tapping Screw (ST4.2 x 20) 4
35 Power Connector (L = 700 mm) 1
36 Motor Wire (L = 600 mm) 1
37 Sensor with Wire (L = 400 mm) 1
38 Extension Sensor Wire (L = 1100 mm) 1
39 Computer 1
40 Phillips Screw (M5 x 10) 2
41 Hand Pulse Sensor Wire 2
42 Flat Washer (ø5 x ø9 x 1.0) 2
43 Phillips Tapping Screw (ST4.2 x 20) 10
44 Handrail Arm Foam Grip 2
45 End Cap for Handlebar 2
46 Seat Cushion 2
