ASSEMBLY STEPS
STEP 3: REAR STABILISER ASSEMBLY
Remove Screw (25) from the Top and Bottom Cover of the Rail (36, 37).
Fix the Top and Bottom Cover of the Rail (36, 37) onto the Steel Rail (33) with Screws (25).
Fix the Rear Stabiliser (38) onto the bottom of the Rail (33) with 4 Washers (3), 4 Spring Washers (11) and 4 Bolts (24).
STEP 3
