Trojan IMAGE 350 - Page 18

10169-18
PARTS LIST
NO Q’TY Description
51 4 M5x12mmAcrossHeadScrew
52 8 M5x15mmMachineScrew
53 2 M5x10mmScrew
54 1 M8x1.25Px74mmAxle
55 2 Ø16xØ10.3x4.8mmSpacerAdjustableWasher
56 1 6200Z Bearing
57 1 M8x1.25Px70mmShoulderBolt
58 1 Ø18.5xØ10.5x11mmBushing
59 2 R12Z Bearing
60 1 Ø26xØ19.84x23.6mmBushing
61 1 M10x20mmAllenHeadScrew
62 1 SensorFixation
63 7 M4x15mmMachineScrew
64 1 Ø254x45.4MagneticFlyWheel
65 1 640J4 Belt
66 2 M8x8mmNylonNut
67 1 C Magnet
68 1 IdleWheelBracket
69 2 Ø14xØ10.5x1.5mmFlatWasher
70 1 Idle Wheel
71 1 Resistance Arm
72 1 Ø26x1.8mmResistanceWasher
73 1 M6x1.0Px9mmAllenHeadBolt
74 1 ¼”x1.0Px44mmAllenHeadbolt
75 1 M6x1.0Px5mmNut
76 1 Ø26xØ19.84x2.8mmSleeve
77 4 M5x4.5mmMotorNut
NO Q’TY Description
78 1 MotorBracket
79 1 Motor
80 4 M5x12mmScrew
81 2 Transportation Wheel
82 4 M8*1.25Px18mmAdjustableKnob
83 6 M5x20mmMachineScrew
84 1 6.35x6.35x12mmKey
85 1 Ø12.57x4.57Magnet
86 1 M5x15mmScrew
87 1 1651mm Upper Cable
88 1 1200mmLinkWire
89 1 Sensor
90 1 Ø25.4x1200mmSmallHandlebarFoamGrip
91 1 250mmLinkWire
92 1 M4x10mmMachineScrew
93 2 Disc Cover
94 1 Ø28xØ6.2x2.5HFlatWasher
95 1 M6x18mmHeadScrew
96 3 6000Z Bearing
97 1 Ø15.7xØ10.2x28mmSpacer
98 7 Ø10xØ5.3x0.6LockWasher
99 2 M5x10mmMachineScrew
100 1 M8x40mmAllenHeadScrew
101 3 Ø16xØ10.4x1.0mmFlatWasher
102 2 4mm Allen Wrench
103 1 6mm Allen Wrench
104 1 Universal Wrench
