Trojan IMAGE 350 - Page 7

10169-7
HARDWARE LIST
NO DESCRIPTION QUANTITY
1/29R&L/2 Main Frame with Chain Cover, Pedal Tube Weld 1 set
7/46/48/12/9/19 FrontPost/AxleDecolation/Washer/Screw/HandPulseWire 1 set
3R&L/27/28/24/25R&L Upper Handle Bar (R&L) with Foam Grip ,End Cap, Hand Pulse Wire, Hand Pulse 1 set
4 Bottom Handle Bar 2
11/51 Monitor with Sensor Wire, 4 Screws 1
40R&L Foot Pedal (R&L) 1 pair
10/90/12/18 Handlebar Weld with Foam Grip, 2 Spring Washer, 2 Screws 1 set
81 Transportation Wheel 2
44 End Cap 2
22/23/8 Handlebar Decoration/ Round Head Screw/Pivot Cover 2 sets
NO Description Q’ty Specification
Drawings
9 Allen Head Screw 4 M8x20mm
12 Spring Washer 4 M8
14 Machine Screw 8 M4x15mm
21 Allen Head Screw 4 M6x16mm
36 AxleCover 4 25*10.5*2mm
39 PedalAxle 2
41 HexHeadScrew 4 M6x35mm
42 Nut 4 M6
82 Adjustable Knob 4 M6
102 Allen Wrench 2 4mm
103 Allen Wrench 1 6mm
104 Universal Wrench 1
