PARTS LIST
No. Description Qty
55 Bolt (GB / T 5780 - 2000 M8 x 40 mm) 2
56 Console (TE - 2300) 1
57 Washer 2 (M10) 1
58 Fixing Nut 2 (M12 x 1.25 mm H = 6) 2
59 Fixing Tube (Ø16 mm x Ø12.1 mm x 35 mm) 1
60 Bearing (6001 ZZ) 2
61 Flywheel (Ø453 mm x 72 mm) 1
62 Flywheel Shaft (Ø12 mm x 160 mm) 1
63 Sensor (SR - 202) 1
64 Domed Nut (GB / T 802 - 1988 M10) 1
65 Lock Nut (M33 mm x 1 mm x 4 mm) 2
66 Nut (M20 mm x 1.0 mm) 1
67 Flywheel Cover (Ø59 mm x 35 mm) 1
68 Spring Cover (32 mm x 23 mm x 2 mm) 1
69 Spring 3 (Ø2.2 mm) 1
70 Plastic Frame (116 mm x 30 mm x 32 mm) 1
71 Little Plastic (14 mm x 9 mm x 14 mm) 1
No. Description Qty
72
Chain Wheel (A7K - 16 1/2” mm x 1/8”
16T) (1.37”)
1
73 Woolly Block (113 mm x 25 mm x 6 mm) 1
74 Bolt 1 (GB / T 5780 - 2000 M5 mm x 30 mm) 2
75 Spring Brake 1.0 1
76 Lock Nut (GB / T 889.1 -2000 M5) 2
77 Spring Washer 1 (GB / T 859 - 1987 5 mm) 3
78 Bolt 2 (GB / T 5780-2000 M5 mm x 10 mm) 2
79 Flat Washer 2 (35 mm x 20 mm x 2.0 mm) 1
80 Screw 4 (GB / 845 - 85 ST4.8 x 13 mm) 1
81 Fixing Tube (Ø16 mm x Ø12.2 mm x 56.2 mm) 1
82 Screw 4 (GB / 845 - 85 ST4.8 x 19 mm) 2
83 Bolt 3 (GB / T 5780 - 2000 M5 mm x 10 mm) 2
84
Left Protect Cover
(255 mm x 185 mm x 84 mm)
1
85
Right Protect Cover
(255 mm x 185 mm x 87 mm)
1
86 Screw 5 (ST 2.9 mm x 12 mm) 2
