HARDWARE & TOOLS LIST

INSTRUCTIONS FOR ASSEMBLY

• Before you start to assemble, please check the hardware packaging to make sure all parts are included.

• Basic tools, such as spanners will be provided for assembly.

#30 (M8 x 73 mm) (4 PCS)

#32 (M8 x 16 mm) (4 PCS)

#14 (M8 x 16 mm) (2 PCS)

#19 (M8 x 75 mm) (2 PCS)

#35 (M8 x 45 mm) (4 PCS)

#10 (M8 x 43 mm) (4 PCS)

#5 (M8 x 30 mm) (2 PCS)

#23 (M5 x 10 mm) (2 PCS)

#21 (M8) (6 PCS)

#39 (M10 x 1.25 mm) (2 PCS)

#41 (D10 x Ø32 x 2 mm) (2 PCS)

#12 (D8 x Ø32 x 2 mm) (2 PCS)

#27 (D8 x Ø20 x R16 x 2 mm) (4 PCS)

#31 (D8 x Ø20 x R30 x 2 mm) (8 PCS)

#18 (D8 x Ø16 x 1.5 mm) (6 PCS)

#4 (D8) (4 PCS)

#28 (M8) (8 PCS)

#6 Cover (1 PC)

#13 (S13) (6 PCS)

#40 (S163) (2 PCS)
