Trojan PULSE 260 User Manual

7
PARTS LIST
No. Description Qty
1 Screw (ST4 x 19 mm) 2
2 Round End Cap (Ø25 x 16 mm) 2
3 Foam Grip (Ø23 x 5 mm x 400 mm) 2
4 Spring Washer (Ø8) 4
5 Screw (M8 x 30 mm) 2
6 Cover 1
7 Foam Grip (Ø30 x 5 mm x 630 mm) 2
8 Ball End Cap (Ø32 x Ø50 x 46 mm) 2
9 L, R Handlebar L, R 2
10 Square Neck Bolt (M8 x 43 mm) 4
11 Bushing 2 8
12 Washer (Ø8 x Ø32 x 2 mm) 2
13 Ball Cap (S13) 6
14 Bolt (M8 x 16 mm) 2
15 Bushing I 4
16 L, R Swing Rod Post L R 2
17 Spacer (Ø14 x Ø8.3 x 59 mm) 2
18 Washer (Ø8 x Ø16 x 1.5 mm) 6
19 Bolt (M8 x 75 mm) 2
20 L, R Pedal Rod Post L, R 2
21 Nylon Nut (M8) 6
23 Screw (M5 x 10 mm) 2
24 Screw (M5 x 40 mm) 1
25 Arc Washer (Ø5 x Ø20 x R30 x 1.5 mm) 1
26 Upright Post 1
27 Arc Washer (Ø8 x Ø20 x R16 x 2 mm) 4
28 Cap Nut (M8) 8
29 Long Spacer (Ø32 x Ø19.2 x 75.5 mm) 2
30 Square Neck Bolt (M8 x 73 mm) 4
No. Description Qty
31 Arc Washer (Ø8 x Ø20 x R30 x 2 mm) 8
32 Screw (M8 x 16 mm) 4
33 End cap (Ø60 x Ø78 x 62 mm) 2
34 Mid-handlebar Post 1
35 Bolt (M8 x 45 mm) 4
36 Pedal (R, L) 2
37 Pulse Wire 1
38 Mid-Sensor Wire 2 1
39 Nylon Nut (M10 x 1.25 mm) 2
40 Ball Cap (S16) 2
41 Washer (Ø10 x Ø32 x 2 mm) 2
42 Short Spacer (Ø32 x Ø19.2 x 30 mm) 4
43 Wave Washer (Ø19 x Ø25 x 0.3 mm) 4
44 End Cap (Ø60 x 45.5 mm) 2
45 Main Frame 1
46 Square End Cap (J60 x 30 mm x 15 mm) 2
47 Washer (Ø6 x Ø12 x 1 mm) 2
48 Pulse Pad (Ø25 mm) 2
49 Mid-Sensor Wire I 1
50 Console 1
51 Tension Wire 1
52 Tension Wire 1
53 Tension Control 1
54 Front Stabiliser 1
55 Rear Stabiliser 1
56 Cross Wrench (S13 - 14 - 15) 1
57 Wrench (S17 - 19) 1
58 Wrench (S13 - 15) 1
59 Wrench (S6) 1
