8
No. Description Qty
60 L, R Front Chain Cover 1
61 L, R Dial 1
62 R Brace E Post 1
62 L Brace E Post 1
63 Nylon Nut 4
64 Spring Washer 4
65 Middle Axis Combine 1
66 Belt Pulley 1
67 Belt 6 (PJ 340) 1
68 Bolt (M6 x S10 x 12 mm) 3
69 Fixed Tray 2
70 Bearing (600 I - 2 RS) 2
71 Bearing Block (Ø72 x 11 mm) 2
72 L, R Chain Cover 2
73 Washer (Ø17) 1
74 Bearing (6203 - 2RS) 2
75 Spacer (Ø22 x Ø18 x 6 mm) 1
76 Screw (M6 x 16 mm) 4
77 Bolt (ST4.2 x 13 mm) 3
78 Axle of wheel 1
79 Bolt (ST4.2 X 13 mm) 3
80 Bolt (ST4.2 x 19 mm) 9
81 Flywheel (Ø200 x 2 mm) 1
82 Bolt (ST4.2 x 16 mm) 4
83 Round Magnet (Ø15 x 7 mm) 2
84 Nut (M10 x 1.25 mm) 2
85 Crank Cover 2
86 Bolt (M6 x S10 x 16 mm) 2
87 Spring Washer (Ø6) 2
No. Description Qty
88 Washer (Ø6 x Ø12 x 1.2 mm) 2
89 Axle Washer (Ø12) 2
90
Axle for Magnet Board (Ø12 x M6 x 61 mm
x 8 mm x 45.5 mm)
1
91 Magnet Board 1
92 Bolt (ST3 x 10 mm) 3
93 Spring Tension (Ø1.5 x Ø15 x N8 x 41 mm) 1
94 Magnet Case (45.5 x 130 x 10.5 mm) 1
95 Magnet (40 x 25 x 10 mm) 4
96 Washer (Ø6 x Ø16 x 1.5 mm) 3
97 Bolt (M6 x Ø12 x 10 mm) 5
98 Bolt (M6 x Ø12 x 8 mm) 1
99 Idle Connecting Rod 1
100 Spring Tension (Ø2.5 x Ø18 x N12 x 64 mm) 1
101 Idle Wheel (Ø39 x Ø34 x 24 mm) 1
102 Bolt (M6 x S1 x 45 mm) 1
103 Nut (M6 x H5 x S10) 1
PARTS LIST
104 Bolt (M8 x 12 mm) 1
