12
STEP 4: CONSOLE INSTALLATION
Attach the Console (10) to the bracket located on the Handlebar (8) using 2 Screws (79). Tighten and secure using
Spanner (25) .
Connect the link wire of the Console (10) to the link wire of Inductor (L = 350) (12).
STEP 4
ASSEMBLY STEPS
