Trojan SPIN 120 - Parts List

6
PARTS LIST
No. Description Qty
1 Main Frame 1
2 Seat Slider 1
3 Magnetic Board 1
4 Handlebar Post 1
5 Seat Slider Tube 1
6 Front Stabiliser 1
7 Rear Stabiliser 1
8 Handlebar 1
9 Front Handlebar (Ø25 X 1.5 X 720) 1
10 Console 1
11 Sensor Wire (L = 650) 1
12 Inductor (L = 350) 1
13 Flat Plate (1.0 X 131 X 185) 1
14 Flywheel 1
15 Bearing (6201 - 2RZ) 1
16 Spacer (Ø18 X Ø12.1 X 24.5) 1
17 Inertial Axle (Ø12 X 165 X M12 X 1.0) 1
18 Bearing (6001 - 2RZ) 1
19 L/R Pedal (HD - 16C 1/2”) 1
20 Spring (Ø1.6 X Ø12 X N18 X 51) 1
21 Brake Rod (Ø10 X 230 X M10 X 20 X M10 X 60) 1
22 Nut (Ø15 X 15 X 25) 1
23 Wave Washer (Ø15.5 X Ø12 X 0.3) 2
24 Magnet (23 X 20 X 5) 3
25 Spanner (S = 13, 14, 15) 1
26 Allen Wrench (S6) 1
27 L/R Crank (205 X 152 X 48 X 1/2” X 20) 1
No. Description Qty
28 Nut (M7/8” X 24- X S32 X 5) 1
29 Washer (Ø33.5 X 22.5 X 2.5) 1
30 Left Thread (M7/8” X 24- X Ø45 X 12) 1
31 Bowl (Ø56 X Ø51.6 X 16) 2
32 Bead groove (Ø45 X Ø20 X 10) 2
33 Right Thread (15/16” X 24- X Ø45 X 12) 1
34 Magnet (Ø15 X 7) 1
35 Flat Washer (Ø38 X 26 X 3) 1
36 Adjusting Bolt (M6 X 45 X Ø12 X 2.5) 2
37 Bushing (Ø22 X Ø12.2 X 5) 2
38 Screw (M8 X 16 X S6) 4
39 Washer (D8.5 X Ø16 X 1.5) 10
40 Nylon Nut (M6 X H6 X S10) 3
41 Nut (M10 X 1.5 X H5 X S17) 1
42 Nylon Nut (M8 X H6.8 X S13) 3
43 Nut (M12 X 1.0 X S19 X H6) 4
44 Nut (M6 X H5 X S10) 4
45 Screw (M6 X 10 X Ø12) 1
46 Screw (ST4.2 X 12 X Ø8) 1
47 Screw (ST4.2 X 20 X Ø10.5) 1
48 Washer (D8 X 20 X 2.0) 2
49 Screw (M8 X 40 X 20) 7
50 Screw (ST4.2 X 19 X Ø8.4) 3
51 Screw (D6 X Ø20 X 2.0) 1
52 Nut (M12 X 1 X H19.5 X S19) 6
53 Screw (M8 X 35 X S5 X 15) 6
54 Screw (M6 X 15) 1
