LOCK NUT
The Lock Nut holds the string.
STRING RECESS
The string recess guides the string.
STRING SHAFT
The string shaft winds the string.
HEX NUT
Use the wrench that comes with the set to
tighten the Hex Nut.
NOTE: do not use any tools on the Lock Nut and do not over tighten. Instead use a 1 CENT
COIN to tighten the locknut, otherwise you may damage the ROBOHEAD by applying too
much force.
Use only supplied wrench or torque wrench to tighten the Hex Nuts (the recommended
torque for the Hex Nuts of the RoboHeads is 1.5 Nm - 1.65 Nm (13.27 in.lbs - 14.6 in-lbs))
