tronical TUNE PLUS - Gain; Guitar Type; Pitch Window

E GAIN
Increase gain if string LEDs don’t turn yellow when first
plucked; decrease gain in environments with high ambient
noise. The default is recommended.
1. When the TronicalTune PLUS is switched off, press
ON three times. Press the LEFT/RIGHT button to
select YELLOW D .
2. Press ENTER twice. The LEFT/RIGHT button
selects the gain amount. More lit LEDs = higher
gain/increased system sensitivity.
3. Press ENTER = gain setting stored.
NOTE: The calibration process (page 33) opti-
mizes gain. We strongly recommend keeping
the default gain setting. However when you are
tuning in loud environments, decreasing the
gain temporarily and/or tuning in Single-String
Tuning mode can improve performance.
A GUITAR TYPE
Set up the TronicalTune PLUS for electric or acoustic guitar
1. When the TronicalTune PLUS is switched off,
press ON three times. Press the LEFT/RIGHT button
to select YELLOW D .
2. Press ENTER. Press the LEFT/RIGHT button to
select the YELLOW A string LED. Press ENTER.
3. The LEFT/RIGHT button selects E for electric,
A E for acoustic, or D A E for short scale guitars.
4. Press ENTER = guitar type setting stored.
D PITCH WINDOW
If you try to use Multi-String Tuning mode but a string
is considerably out of tune, the TronicalTune PLUS
switches to Single-String Tuning mode automat-
ically. This function sets how far off-pitch a string
must be before the TronicalTune PLUS switches to
Single-String Tuning mode.
1. When the TronicalTune PLUS is switched off,
press ON three times.
2. Press the LEFT/RIGHT button to select YELLOW D .
Press ENTER.
3. Press the LEFT/RIGHT button to select YELLOW D .
Press ENTER.
4. The LEFT/RIGHT button selects the pitch window.
1 lit LED = 150 cents
2 lit LEDs = 100 cents
3 lit LEDs = 75 cents
4 lit LEDs = 50 cents
5 lit LEDs = 35 cents
all LEDs lit = 25 cents
5. Press ENTER = pitch window setting stored.
E
A
D
G
B
CATEGORY FUNCTIONS
Gain
Guitar Type
Pitch Window
Low Tunings
Tuning Offset
37
