E CALIBRATION MODE
Before calibration tune the guitar to standard
pitch! (red tuning bank E LED).
1. When the TronicalTune PLUS is switched off,
press the ON button.
2. Strum the open strings once.
3. When all LEDs are GREEN , all six strings
are tuned. The TronicalTune PLUS turns off
automatically (if any LEDs are not green, pluck those
strings individually).
NOTE: You must calibrate the TronicalTune PLUS:
- after installing for the first time
- if you change your strings’ gauge, type, or brand
- if you perform a master system reset or firmware update
- if you are facing issues like erratic ROBOHEAD
movements, strings not tuning properly, etc.
CALIBRATION:
1. Press ON three times. Press the LEFT/RIGHT
button to select CYAN A .
2. Press ENTER twice. The string LEDs blink RED .
3. Strum all strings once. All lights should shine
GREEN briefly then turn off. If the LEDs continue to
flash RED , mute all strings and then strum again.
4. Once the strings have turned off from being
GREEN , or show a combination of BLUE and
RED LEDs, mute all strings. Then all string LEDs
blink RED .
5. Repeat steps 3 and 4 until the LEDs light
SEQUENTIALLY and one string LED is lit.
E
A
D
G
B
Calibration Mode
Accuracy Level
RoboHead Delay
RoboHead Speed
Interference Level
CATEGORY FUNCTIONS
33
