tronical TUNE PLUS - Page 41

Apply an offset to any string with individual pitch up/down to ±12 cents (a cent is 1/100th of a semitone)
NOTE: Pitch Offset applies to the last completed tuning. Please choose, select and tune to a tuning preset
before applying the per-string pitch offset. Pitch offset will remain applied to this tuning until you change
its pitch offset, reset the bank or reset the system.
1. When the TronicalTune PLUS is switched off, press ON three times.
Press the LEFT/RIGHT button to select MAGENTA G . Press ENTER.
2. The LEFT/RIGHT button choose the MAGENTA LED for the string you want to offset. Press ENTER.
3. Press the LEFT/RIGHT button to change the string’s pitch offset:
• If no previous offset exists, all string LEDs flash WHITE . Each LEFT button press lights a GREEN LED
and offsets the pitch by +1 cent (up to +6 cents). Continuing to press the LEFT button lights YELLOW
LEDs. Each lit YELLOW LED offsets the pitch by another +1 cent (+7 to +12 cents maximum).
• Each RIGHT button press lights a RED LED and offsets the pitch by -1 cent (up to -6 cents). Continuing
to press the RIGHT button lights MAGENTA LEDs. Each lit MAGENTA LED offsets the pitch by another
-1 cent (-7 to -12 cents maximum).
• If an offset already exists, the TronicalTune PLUS displays the offset amount as described above. In this
case RIGHT or LEFT button presses continue on from the existing offset. Example: If 12 MAGENTA LEDs
are lit to indicate -12 cents of offset, pressing the LEFT button will turn off successive MAGENTA LEDs,
then turn off successive RED LEDs, then start lighting GREEN LEDs.
4. Press ENTER. To offset additional strings, repeat steps 2- 4.
Otherwise, press and hold the ON/BACK/OFF button to turn off the TronicalTune PLUS.
PLEASE NOTE: if you have a left-hand or reverse system the navigation step 3 will be vice versa.
41
