Operating manual – dehumidifier TTK 68 E / TTK 69 E
Spare parts list TTK 69 E
No. Spare part No. Spare part No. Spare part
1 Front Panel 21 Crank 41 Proximity Switch
2 Filter Sub-Assy 22 Stepping Motor 42 Cover of drainage hole
3 Lower Sealplate 23 Air Flue Assy 43 Rubber Plug
4 Baffle Plate 24 Diversion Circle 44 Water Tray
5 Front Case Assy 25 Centrifugal Fan 45 Discharge Tube Sub-Assy
6 Light Penetrating Board 26 Fan Motor 46 Baffle Plate
7 Front Case 27 Propeller Housing 47 Compressor and Fittings
8 PCB 28 Rear Cover Assy 48 Chassis Sub-Assy
9 Display Box 29 Rear Cover 49 Castor
10 Display Board 30 Cover of drainage hole 50 Cable Clamp
11 Button 31 Tieline of Power Cord 51 Inhalation Tube Sub-assy
12 Front Panel Clip 32 Water Tank Assy 52 Power Cord
13 Cover Plate Assy 33 Water Tank Cover 53 Electric Box Assy
14 Cover Plate 34 Float Meter Sub-Assy 54 Electric Box
15 Detecting Plate 35 Water Tank 55 Insatallation Box(Main Board)
16 Baffle Plate (Temperature & Humidity Sensor) 36 Heat-exchange Equipment 56 Main Board
17 Front Grill Sub-assy 37 Condenser Sub-Assy 57 Capacitor
18 Front Grill 38 Evaporator Sub-Assy 58 Capacitor CBB61
19 Guide Louver 39 Capillary Sub-Assy 59 Electric Box Cover
20 Air Guide Bushing 40 Water Tray Assy
Disposal
In the European Union, electronic equipment must not be
treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2002/96/EC of the
European Parliament and of the Council of 27January 2003 on
waste electrical and electronic equipment (WEEE). At the end of
its life, please dispose of this device according to the valid legal
requirements.
The device uses an environmentally and ozone-neutral cooling
agent (see Technical Data).
Dispose of the refrigerant appropriately and according to the
national regulations.
