Trotec TTK 68 E - Transport and storage; Transport; Storage

EN 4
Operating manual – dehumidifier TTK 68 E / TTK 69 E
TTK 69 E
1
2
3
5
6
9
8
3
7
4
No. Designation
1 Control panel
2 Air inlet
3 Cover of condensation drain hose connection
4 Wheels
5 Transport handle
6 Power cable
7 Condensation tank
8 Air outlet
9 Front cover with air filter
Transport and storage
Transport
To make the device easier to transport, it is fitted with wheels.
Before transporting the device, proceed as follows:
1. Pump out any possibly remaining condensate. Check for
dripping condensation.
2. Pull the plug from the mains socket. Do not use the power
cable to drag the device.
3. Only wheel the device on a level and smooth surface.
Storage
Drain any possibly remaining condensate.
When the device is not being used, observe the following
storage conditions:
• In an upright and stable position.
• Dry.
• Protected from dust and direct sunlight.
• With a cover to protect it from invasive dust, if necessary.
