Trox Technik FKR-EU - Page 2

Fire dampers
General information
03/2017
FKR-EU
– DE/en
1
Type
FKR-EU General information 1.1 – 2
Correct use 1.1 – 8
Order code 1.1 – 12
Installation kit TQ 1.1 – 13
Cover grille 1.1 – 14
Flexible connector 1.1 – 16
Extension piece 1.1 – 19
Limit switch 1.1 – 21
Spring return actuator 1.1 – 22
TROXNETCOM 1.1 – 23
Duct smoke detectors 1.1 – 24
Quick sizing 1.1 – 25
Free area and resistance coefficient 1.1 – 26
Dimensions and weight – FKR-EU 1.1 – 27
Dimensions and weight – FKR-EU/.../Z4* 1.1 – 28
Dimensions and weight – FKR-EU/.../ZEX* 1.1 – 29
Dimensions and weight – FKR-EU-FL 1.1 – 30
Dimensions and weight – FKR-EU-FL/.../Z4* 1.1 – 31
Dimensions and weight – FKR-EU-FL/.../ZEX* 1.1 – 32
Flange holes 1.1 – 33
Specification text 1.1 – 34
Basic information and nomenclature 1.3 – 1
Page
K4 – 1.1 – 2
Variants
Product examples
FKR-EU with fusible link FKR-EU-FL with spring return actuator
FKR-EU
with explosion-proof spring return actuator
