Add En{jineOil and Fuel
• Place pressure washer on a level surface•
NOTE:Verify provided oil bottle is the correct viscosity for
current ambient temperature•
• Referto engine operator's manualand follow oil and
fuel recommendationsand instructions•
NOTICE
Anyattempt to crank OFstart the engine before it has been
properly filled with the recommendedoil will result in
_ment failure•
Referto enginemanualfor oilandfuel fill information•
Damageto equipmentresultingfromfailureto followthis
instructionwillvoidwarranty•
NOTE:Checkoil often during engine break-in• Referto
engine operator's manualfor recommendations•
Connect Hoseand Water Supply to Pump
NOTICE
DONOTFunthe pump without the water supply connected
and turned on. _ _ _ m
I" Damageto equipmentresultingfromfailureto followthis
h instructionwill voidwarranty•
NOTE:Removeand discard the shipping caps from the
pump's high pressure outlet and water inlet beforeattaching
hoses•
1. Uncoil high pressure hose and attach one end of hose
to baseof spray gun. Tighten by hand•
WARNING
The high pressurestream of water that this
_ quipment produces can cut through skin and its
underlyingtissues, leadingto serious injury and
3ossible amputation•
• NEVERconnecthighpressurehoseto nozzleextension•
, Keephighpressurehoseconnectedto pumpandspraygun
whilesystemis pressurized•
, Alwaysbecertainspraygun,nozzlesandaccessoriesare
correctlyattached•
2. Attach other end of high pressure hose to high
pressure outlet on pump• Tighten by hand•
3. Run water through your garden hose for 30 seconds to
clean outany debris•
IMPORTANT:DO NOTsiphon standing water for the water
supply• UseONLYcold water (less than I O0°F).
4. Beforeconnecting garden hose to water inlet, inspect
inlet screen (A). Cleanscreen if it contains debris or
haveit replacedif damaged•DO NOTFunpressure
washer if inlet screen is damaged•
5. Connectthe garden hose (not to exceed50 feet in
length) to the water inlet•Tighten by hand•
NOTICE
Damageto pump or water inlet connector will occur if a
OneWay Valve (vacuumbreaker or check valve) is
connectedto pump•
ThereM/USTbeat leasttenfeet(31Vl)of unrestrictedgarden
hosebetweenthe pressurewasherinletandanydevice,suchas
aOneWayValve•
Damageto equipmentcausedby attachinga OneWayValveto
pumpwill voidwarranty•
6. Turn ONthe water and squeezethe trigger on the spray
gun to purge the pump system of air and impurities•
WARNING
Riskof eye injury.
• _ ISpray cansplash back or propel objects•
Alwayswearsafetygoggleswhenusingthis equipmentor in
vicinityofwhereequipmentis in use.
Beforestartingthepressurewasher,besureyouarewearing
adequatesafetygoggles•
NEVERsubstitutesafetyglassesforsafetygoggles•
Checklist Before Starting Engine
Reviewthe unit's assembly to ensureyou have performed all
of the following•
1. Be sure to readthe Operator Safetysection and How to
Use Your Pressure Washerin Operationsection before
using pressure washer•
2. Make sure handle is in place and secure•
3. Checkthat oil hasbeen addedto proper levelin the
engine crankcase•
4. Add proper fuel to fuel tank•
5. Checkfor properly tightened hose connections•
6. Checkto makesure there are no kinks, cuts, or damage
to high pressure hose•
7. Providea proper water supply at an adequateflow•
