Assembly & Set-Up
3
7
Assembly
Handle
1. Place the shift lever in the Forward-6 position.
2. Observe the lower rear area of the snow thrower to be sure
both cables are aligned with roller guides before pivoting
the handle upward. See Figure 3-1.
Figure 3-1
NOTE: Make certain the cables are seated properly in the
roller guides. See Figure 3-2.
Figure 3-2
3. Secure the handle by tightening the plastic knob located
on both the left and right sides of the handle. Remove
and discard any rubber bands, if present. They are for
packaging purposes only.
Contents of Carton
• One Snow Thrower • Two Replacement Auger Shear Pins • One Electric Start Cord
• One Snow Thrower Operator’s
Manual
• One Product Registration Card • One Chute Control Rod
• One Chute Assembly • One Engine Manual
