True TAC-48 - Legs, Leveling, and Wiring Preparation

............ www.truemfg.com ............
True Food Service Equipment, Inc.
7
7
INSTALLATION / OPERATION INSTRUCTIONS
Leg levelers in the bottom of the cabinet
can be backed out for leveling.
Leg Levelers:
Ifthecabinetisnotleveluseanopen-endwrenchandturn
adjustabletipsonlegsuntilcoolerislevel.(Seeimage1).
Castor Installation:(KitContents)
2-Castormountingbracket
2-Castor,2-1/2”diameterwheelwith3/8”-16x1- 
1/2”threadedstemwithoutbrake
2-Castor,2-1/2”diameterwheelwith3/8”-16x1- 
1/2”threadedstemwithbrake
4-Washer,flat,3/8”I.D.x1”O.D.
4-Washer,splitlock,3/8”I.D.
4-Nut,hex,3/8”-16
(See image 2).
CAUTION
To avoid damage to lower rail assembly, slowly raise unit to
upright position after installing castors.
2
A. Beforeyournewunitisconnectedtoapowersupply,
checktheincomingvoltagewithavoltmeter.If
anythinglessthan100%oftheratedvoltagefor
operationisnoted,correctimmediately.
B. Allunitsareequippedwithaservicecord,andmust
bepoweredatproperoperatingvoltageatalltimes.
Refertocabinetdataplateforthisvoltage.
TRUErequiresthatasolecircuitbededicatedfortheunit.
Failuretodosovoidswarranty.
WARNING
Compressor warranties are void if compressor burns out due
to low voltage.
WARNING
Power supply cord ground should not be removed!
WARNING
Do not use electrical appliances inside the food storage
compartments of the appliances unless they are of the
type recommended by the manufacturer.
NOTE
To reference wiring diagram - Remove lower rear grill. Wiring
diagram is positioned on the inside cabinet wall.
ELECTRICAL INSTRUCTIONS
LEVELING
Securing Castors
A. Setunitinitsfinallocation.Besurethereisadequate
ventilationinyourroom.Underextremeheat
conditions,youmaywanttoinstallanexhaustfan.
WARNING
Warranty is void if ventilation is insufficient.
B. ProperlevelingofyourTRUEcooleriscriticalto
operatingsuccess(fornon-mobilemodels).Effective
condensateremovalanddooroperationwillbe
effectedbyleveling.
C. Thecoolershouldbeleveledinsidethecabinetfront
tobackandsidetosidewithalevel.
D. Ensurethatthedrainhoseorhosesarepositionedin
thepan.
E.  Freeplugandcordfrominsidethelowerrear
ofthecooler(donotplugin).
F. Theunitshouldbeplacedcloseenoughtothe
electricalsupplysothatextensioncordsarenever
used.
WARNING
Cabinet warranties are void if OEM power cord is tampered
with. TRUE will not warranty any units that are connected to an
extension cord.
INSTALLATION OF LEGS AND CASTORS
1
