BARBEQUE MODELS AND OPTIONS
B60 AND B90
Model Burners
Total
Width
(mm)
Total
Width of
Barbeque
Plates
(mm)
*Optional
Solid Grill
Section
(mm)
B60 2 600 550 *275
B90 3 900 825 *275
* Only one solid grill plate may be fitted to each Barbeque – each Barbeque
must have at least two (B60) or four (B90) Barbeque grill plates fitted (Operator
Manual refers).
GENERAL SPECIFICATIONS
OVERALL DIMENSIONS AND WEIGHT
MODEL HEIGHT
(mm)*
WIDTH
(mm)
DEPTH
(mm)
WEIGHT
(Kg)
B60
Assembled on Stand 910* 600 803 110
Shipping 800 730 930 150
B90
Assembled on Stand 910* 900 803 135
Shipping 800 1030 930 180
* Excluding Backguard – 1125mm including backguard.
Detailed dimensional specifications are shown at the rear of this manual
.
Barbeque Manual Page 10 Revision: 13 Sep 07
OPERATOR MANUAL B60 B90 130907.doc
