BARBEQUE BURNERS
Barbeque Burner Control
NOTE: Ensure the gas supply to the equipment is turned ON
Pilot Flame Ignition
Starting from the OFF ● position, press the control knob and rotate to the
PILOT ★ position.
Press the control knob and then press the piezzo igniter to ignite the pilot flame
– repeat until the pilot ignites (the pilot flame can be viewed through the front
panel). Keep the knob fully depressed for 15 seconds after the pilot lights.
Release the knob and check the pilot flame stays alight. If the pilot flame did
not stay alight, repeat the ignition procedure.
Barbeque Burner Ignition
Slightly depress the control knob and rotate to the LEVEL 1 or LEVEL 2
position.
When the automatic valve senses that the pilot is alight, the gas flow to the
main burner is opened.
Barbeque Manual Page 12 Revision: 13 Sep 07
OPERATOR MANUAL B60 B90 130907.doc
