Data Plate: The data plate is located behind the front panel
and is accessed by removing the control knobs
and then the front panel.
Installation Clearances: The MINIMUM clearance from combustible
surfaces is;
Sides 150 mm, and
Rear 50mm
Adequate clearance must also be provided for
service.
Stand:
The Barbeque is provided with a stand. The
Barbeque is positively located on the stand by
inter-locks on the underside of the Barbeque.
WARNING: Ensure the Barbeque is positively
located on the stand.
Adjustable feet are included on the stand legs and
allow the unit to be levelled to the floor in the
installed location.
Levelling: To adjust the legs to level the unit to the floor
and/or to slightly adjust the height of the unit, raise
the front of the unit and adjust the legs (ensure
safe work practices). Similarly, raise the back of
the unit and adjust the legs. DO NOT LAY THE
UNIT ON ITS BACK. ENSURE THE UNIT IS
LEVEL.
Barbeque Manual Page 8 Revision: 13 Sep 07
OPERATOR MANUAL B60 B90 130907.doc
