B380EN04.doc Operation 4-91
8.4 TOOLING Rail allocation
If two or more tools with the same ID number are on the tool rail,
the tool manager selects the tool for machining which is allowed for
the sheet thickness used. If no tool is allowed for the sheet
thickness used, the first one in numerical order is selected.
8.5 TOOLING tool allocation
Softkeys:
Re-locate
clamp
Press the Re-locate clamp softkey if you want to move a clamp
from one rail station to another one.
Load/Unload
clamp
Actuate the Load/Unload clamp softkey if you want to additionally
set up a clamp on the tool rail or unload a clamp from the rail.
Modify
tool data
Actuate the Modify tool data softkey to modify the tool data of the
selected tool. Only the following values can be subsequently
changed: regrind length, whisper tool yes/no, presser foot type,
permissible sheet thickness, optimized forming position.
In the "TOOLING - Rail allocation" menu, the current tool rail
allocation of the machine is displayed, the clamps are loaded and
unloaded and rail positions can be disabled or enabled. The
standard allocation of the tool rail can also be defined. Tools must
be set up by creating manual or automatic tool set-up lists, which
cannot be performed within this menu.
The current allocation of the TRUMATOOLS with tools is displayed
in the menu "TOOLING - Tool allocation". Tool stations can be
disabled or enabled. A standard allocation of the tools can also be
defined. Tools must be set up by creating manual or automatic tool
set-up lists, which cannot be performed within this menu.
