TruXedo Inc. • 2209 Kellen Gross Drive Yankton, SD 57078 • 877-878-9336 • truxedo.com ©TruXedo Inc., 2022
Part# 1118240 Rev. D 8.18.22
Unroll cover to tailgate. Push down on both ends of the cover (A), near the
tailgate, to latch the driver and passenger slam latches.
A clicking sound will indicate a correctly installed cover.
Secure the hook and loop down both sides along the
entire length of the truck bed cover before driving
the vehicle. This will prevent wind from lifting the cover and
causing damage.
NOTE: If you have a key lock tailgate,
the truck bed cover is secured until
the tailgate is unlocked and opened.
9 10
11 12
Preferred method of closure: Close tailgate, then
close cover on top of tailgate. This method will not
work with some truck applications. Use alternative method
instead.
Alternative method of closing cover: Close and latch
cover, then close tailgate with the seal inside the tailgate. It
will take a little time to train the seal to close on the inside.
Rear Header
Seal Seal
Rear Header
PREFERRED ALTERNATIVE
Tailgate
Tailgate
To connect the cover assembly (A) to the side rails (B & C), slide the right and le header guides into the locked posion.
A clicking sound will indicate a secure aachment.
8
LEFT HEADER GUIDE
RIGHT HEADER GUIDE
A
B
C
NOTE: Make sure cover is securely latched
on both sides before operating vehicle.
NOTE: The rail may need to be forced
upward slightly to allow the header
guides to slide.
A
