Roll cover tight. Secure the cover appropriately using
both retainer straps. Do not over tighten. Do not stow
cover against cab window.
Before driving with the cover
open, both straps must be
secured to retaining loops. Failure
to do so could cause accidental
release of the cover, resulting
in personal injury or property
damage.
To release strap push tab up.
NOTE: Ice buildup within hinge
sections can occur if cover is
stowed in open position. To
prevent potential damage, close
cover during winter precipitation.
SECURING THE COVER
ATTENTION:
After the initial installation leave cover closed and latched for 24 hour period. This will ensure that the fabric has completely
set to the metal substrate.
To open cover, pull down on release cable and hold down. Lift and roll tail header toward the cab.
OPENING THE COVER
