- 10 -
1.2 Product Features
MH261T MH361T
Resolution
Printing method Thermal transfer and direct thermal
Max. print speed 305 mm (12”)/second 254 mm (10”)/second
Max. print width 168 mm(6.61”)
Max. print length 14,732 mm (580“) 6,604 mm (260“)
Enclosure Die-cast print mechanism with large clear media view window
Physical dimension
357 mm (W) x 313 mm (H) x 514 mm (D)
14.05” (W) x 12.32 (H) x 20.24” (D)
Weight 17.8 kg (39.24 lbs)
Label roll capacity 208.3 mm (8.2”) O.D.
Internal rewinder (full roll)
Internal rewinder kit (5” O.D.) (dealer option)
Ribbon capacity 450 meter long, max. OD 81 mm, 1“ core (Ink coated outside or inside)
Ribbon width 50.8 mm ~ 178 mm (2”~7”)
Processor 32-bit RISC CPU
Memory
256MB SDRAM
microSD Flash memory card reader for Flash memory expansion, up to 32
Interface
Parallel
USB 2.0 (High speed mode)
Internal Ethernet, 10/100 Mbps
USB host *2 (Front side), for scanner or PC keyboard
GPIO (DB15F) (dealer option)
Slot-in 802.11 a/b/g/n/ac Wi-Fi with Bluetooth 4.2 combo module (dealer
Power
Auto sensing power supply
Input: AC 100-240V, 4-2A, 50-60Hz
Output: DC 5V, 5A; DC 24V, 7A; DC 36V, 1.4A; Total 243W
LCD display/ Operation
buttons
Multi-language selectable
6 operation buttons (menu, select, up, down, left/pause, right/feed)
1 LED (with 2 LEDs Green & Red)
LCD 4.3” color display , 480 x 272 pixel; Resistive touch screen
Sensors
Gap transmissive sensor (Position adjustable)
Black mark reflective sensor (Bottom black mark sensor, Position
adjustable)
Ribbon end sensor
Ribbon encoder sensor
Head open sensor
Real time clock Standard
Internal font
8 alpha-numeric bitmap fonts
Monotype Imaging® CG Triumvirate Bold Condensed scalable font
