TSC MH261T Series User Manual

- 21 -
4. Thread the ribbon through the ribbon sensor slot and then through the open space in between
print head and platen.
5. Wind the ribbon clockwise about 3~5
circles onto the ribbon rewind
spindle until it is smooth and
properly stretched.
6. Close the print head mechanism
by pushing down on both right and
left sides of the deck, making sure
the latches are engaged securely.
Ribbon
sensor
Ribbon
