TSC MH261T Series User Manual

- 55 -
The printing position of small
label is incorrect
* Media sensor sensitivity is
not set properly.
* Label size is incorrect.
*
The parameter Shift Y in the
LCD menu is incorrect.
*
The vertical offset setting in
the driver is incorrect.
* Calibrate the sensor sensitivity again.
* Set the correct label size and gap size.
* Press [Menu]  [Setting]  [Shift X] to
fine tune the parameter of Shift X.
* If using the software BarTender, please
set the vertical offset in the driver.
LCD panel is dark and keys
are not working
*
The cable between main PCB
and LCD panel is loose.
* Check if the cable between main PCB
and LCD is secured or not.
LCD panel is dark but the
LEDs are light
* The printer initialization is
unsuccessful.
* Turn OFF and ON the printer again.
* Initialize the printer.
Ribbon encoder sensor
doesn’t work
* The ribbon encoder sensor
connector is loose.
* Fasten the connector.
Ribbon end sensor doesn’t
work
* The connector is loose.
* The ribbon sensor hole is
covered with dust.
* Check the connector.
*
Clear the dust in the sensor hole by the
blower.
Cutter is not working
* The connector is loose. * Plug in the connect cable correctly.
