TSC Printronix MB240T User Manual

2
1.1 Product Specification
Model
MB240
MB340
MB240T
MB340T
Resolution
8 dots/mm (203 dpi)
12 dots/mm (300 dpi)
8 dots/mm (203 dpi)
12 dots/mm (300 dpi)
Printing method
Thermal Transfer & Direct Thermal
Max. print speed
304.8mm (12")/second
228.6mm (9")/second
304.8mm (12")/second
228.6mm (9")/second
Max. print width
107mm (4.25")
105.7mm (4.16")
107mm (4.25")
105.7mm (4.16")
Max. print length
25,400mm (1000")
11,430mm (450")
25,400mm (1000")
11,430mm (450")
Enclosure
Die-cast based print mechanism/Metal cover with large clear media view window
Physical dimension
248mm (W) x 274mm (H) x 436mm (D)
9.76" (W) x 10.79" (H) x 17.17” (D)
Weight
9 kg (19.84 lbs.)
9.2 kg (20.28 lbs.)
Label roll capacity
203.2mm (8") O.D.
Ribbon
450m long, max. O.D. 81.3mm, 1" core (ink coated outside or inside)
Ribbon width
40 to 110mm (1.6" to 4.3")
Processor
32-bit RISC CPU
Memory
128 MB Flash memory
128 MB SDRAM
Interface
◼ RS-232
◼ USB 2.0
◼ Internal Ethernet (10/100 Mbps)
◼ USB host (for scanner or PC keyboard)
◼ GPIO (dealer option)
◼ Internal Bluetooth 4.2 MFi (factory option)
◼ Slot-in 802.11 a/b/g/n wireless (dealer option)
Power
Internal universal switching power supply
◼ Input: AC 100-240V, 2.0A, 50-60Hz
◼ Output: DC 24V, 3.75A, 90W

TSC Printronix MB240T Specifications

General

Type	Industrial Barcode Printer
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi
Max. Print Speed	6 ips
Max. Print Width	4.09" (104 mm)
Media Type	Label, Tag, Ticket
Media Core Diameter	1" (25.4 mm)
Ribbon Core Diameter	1 inch
Interface	USB, Serial, Ethernet
Power	100-240 VAC, 50/60 Hz
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, POSTNET, PDF417, QR Code, Data Matrix, MaxiCode
Operating Temperature	41°F to 104°F (5°C to 40°C)
