TSC Printronix MB240T User Manual

63
Item
Description
Vertical Length Adjustment (ON)
Turns on/off the Vertical Length Adjustment function. Setting option: ON / OFF.
Vertical Percentage
Adjusts the label length. This item will not appear if Vertical Length Adjustment is turned off. Setting
range: 90 to 115%.
Offset
Specifies the stop position for each operation. Setting range: -203 to 203 dots.
Shift Y
Specifies the amount to shift an image vertically up or down for precise print position on the label.
Setting range: -203 to 203 dots.

TSC Printronix MB240T Specifications

General

Type	Industrial Barcode Printer
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi
Max. Print Speed	6 ips
Max. Print Width	4.09" (104 mm)
Media Type	Label, Tag, Ticket
Media Core Diameter	1" (25.4 mm)
Ribbon Core Diameter	1 inch
Interface	USB, Serial, Ethernet
Power	100-240 VAC, 50/60 Hz
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, POSTNET, PDF417, QR Code, Data Matrix, MaxiCode
Operating Temperature	41°F to 104°F (5°C to 40°C)
