TSC Printronix MB240T User Manual

72
Linerless Platen Roller
1. Turn off the printer.
2. Open the media cover and printhead.
3. Apply some cleaning solution on a lint-free cloth and then wipe off the
adhesive, particles, and dust that build up on the platen roller. Rotate
the platen roller to make sure the platen roller is entirely cleared.
Clean as needed of after printing
every 1 km.
Printhead
1. Turn off the printer.
2. Open the media cover and printhead.
3. Wait until the printhead cools down. It takes at least one minute.
4. Use the supplied cleaning pen in the linerless cleaning kit to clean the
surface of the print head.
Clean as needed or after printing
every 1 km.
Linerless Cutter Module
Refer to 8.2.3 Cleaning the Cutter Blade for detailed information.
Clean as needed or after printing
every 1 km.

TSC Printronix MB240T Specifications

General

Type	Industrial Barcode Printer
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi
Max. Print Speed	6 ips
Max. Print Width	4.09" (104 mm)
Media Type	Label, Tag, Ticket
Media Core Diameter	1" (25.4 mm)
Ribbon Core Diameter	1 inch
Interface	USB, Serial, Ethernet
Power	100-240 VAC, 50/60 Hz
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, POSTNET, PDF417, QR Code, Data Matrix, MaxiCode
Operating Temperature	41°F to 104°F (5°C to 40°C)
