TSC Printronix MB240T User Manual

76
8. Wipe off the adhesive, particles, or dust from the cutter blade and cutter gate.
9. After cleaning the cutter blade, close the upper bar for the cutter gate ensuring the upper bar clicks in place.
10. Close the printhead ensuring the printhead is firmly secured in place.
11. Turn on the printer. The cutter blade will automatically sink into the chassis of the cutter module.
Note: The image below shows that the cutter blade has sunk into the chassis after turning on the printer.

TSC Printronix MB240T Specifications

General

Type	Industrial Barcode Printer
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi
Max. Print Speed	6 ips
Max. Print Width	4.09" (104 mm)
Media Type	Label, Tag, Ticket
Media Core Diameter	1" (25.4 mm)
Ribbon Core Diameter	1 inch
Interface	USB, Serial, Ethernet
Power	100-240 VAC, 50/60 Hz
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, POSTNET, PDF417, QR Code, Data Matrix, MaxiCode
Operating Temperature	41°F to 104°F (5°C to 40°C)
