Operation 27
Use the and arrow keys to view statistics of all the
measurement parameters stored in a Test ID.
Example: TEST 001 has 9 samples, each sample consists of a
pressure, temperature, and relative humidity reading. Use the <
or > keys to view statistics of each measurement parameter.
The 9565 can send this data to the optional Model 8934 wireless
printer or PC capable of Bluetooth communications. To use the
PRINT command, Bluetooth communications must be established
between the 9565 and the Model 8934 wireless printer or PC set
up with Bluetooth communications.
View Samples
TEST 001
Pressure
Avg 1.739 in. H2O
Min 1.665 in. H2O
Max 1.812 in. H2O
# Samples 9
10/31/08 07:01:39 AM
PRINT
TEST 001
Temperature
Avg 78.2 F
Min 78.1 F
Max 78.3 F
# Samples 9
10/31/08 07:01:39 AM
PRINT
TEST 001
%RH
Avg 12.2 %RH
Min 11.1 %RH
Max 12.9 %RH
# Samples 9
10/31/08 07:01:39 AM
PRINT
VIEW DATA
Choose Test Test 001
View Stats
View Samples
Print Test
To Next Page
