2: Setup 9
3. High Flow module only: install pressure tubing (Figure 5).
Attach one end of the pressure tubing to the low-pressure port on
the flow module, and the other to the pressure port in the circuit.
Pressure
tubing
High Flow module
Figure 5. Attaching Pressure Tubing to the High Flow Module
