Page #31 background image
Technical Section 23
CONFIGURE MENU
MENU ITEM
Monitor/
Controller
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
ANALOG OUTPUT
FULL SCALE
FHM10 and FHC50
ANALOG
OUT F.S.
The ANALOG OUT F.S. item selects the full scale range that the
ANALOG OUTPUT SIGNAL will represent. If ANALOG OUT
TYPE is set to velocity, the ANALOG OUT F.S. item can be set
between 0 to 1000 ft/min. If ANALOG OUT TYPE is set to flow
rate, the ANALOG OUT F.S. item can be set between
0 to 10,000 cfm. See menu item ANALOG OUT TYPE. If
ANALOG OUT TYPE is set to % Sash Open, the ANALOG
OUT F.S is set to 100%.
0 to 1000 ft/min
or
0 to 10000 cfm
or
100% to 105%
1000 ft/min
RELAY OUTPUT
DIRECTION
FHM10 and FHC50
RELAYS OUT
The RELAYS OUT item configures the state of the alarm relays.
Select OK=OPEN for normally open (N.O.) relays that close
during alarm conditions. Select OK=CLOSED for normally closed
(N.C.) relays that open during alarm conditions.
NOTE: Relays will always close during power loss conditions.
OK = OPEN
or
OK = CLOSED
OK = OPEN
RELAY OUTPUT 1
SELECT
FHM10 and FHC50
RELAY SEL A
The RELAY SEL A item shows the desired alarm output to be
used with Relay Contact Output 1.
Low Alarm
None
(Read-only value)
RELAY OUTPUT 2
SELECT
FHM10 and FHC50
RELAY SEL B
The RELAY SEL B item selects the desired alarm output to be
used with Relay Contact Output 2. Relay B can be set to toggle
the relay when the unit is in high alarm, high sash alarm, setback
mode, or damper alarm setpoint.
FHM10: High Alarm,
Setback, Sash Open
FHC50: High Alarm,
High Sash, Setback,
Damper Open
High Alarm
