38 Part Two
CALIBRATE FLOW SUBMENU
LINEAR FLOW STATION ONLY
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
FLOW STATION
TOP VELOCITY
FHM10 and
FHC50
FLO STA TOP
VEL
The TOP VELOCITY item is used to input the maximum
velocity of a linear flow station output. A TOP VELOCITY
must be input for the linear flow station to operate.
0 to 10,000 ft/min
(0 to 50.8 m/s)
0 ft/min
(0 m/s)
FLOW STATION
OUTPUT RANGE
FHM10 and
FHC50
FLO STA
FS V
The FLO STA FS V item is used to set the voltage signal
output range of the pressure transducer. Set this item to
match the pressure transducer used.
0 to 5V, 0 to 10V
0 to 10V
FLOW K FACTOR
FHM10 and
FHC50
FLOW KFACTOR
The K FACTOR menu item sets the ā€œKā€ factor for the flow
signal. The flow signal is multiplied by the K FACTOR so
that the flow measurement matches the actual flow,
determined with a pitot tube traverse.
NOTE: FLOW K FACTOR modifies the entire range of the
calibrated flow, not just a single point.
0.01 to 10.00
1.00
CALIBRATE FLOW SUBMENU
LOM VENTURI VALVE ONLY
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
FLOW DEVICE
SELECTED
FHM10 and FHC50
FLOW DEVCE =
This item displays the FLOW DEVICE that was previously
selected through the CONFIG WIZARD item.
Lin Flo Sta
Press Flo Sta
LOM Venturi
6pt Venturi
Calculated
LOM Venturi
(Read-only
value)
