AMU2-8HD+/3G 10 Issue 1
3.5 External Connector – D15 Plug
D15 EXTERNAL
PIN FUNCTION
1 Dim
2 Cut
3 GPI
4 Cut
5 Lt Rt enable
6 GPI
7 N/C
8 N/C
9 N/C
10 N/C
11 N/C
12 N/C
13 N/C
14 +5V
15 0V
3.6 S/HD connectors
This input auto detects HD or SDV signals.
3.7 Re clocked connector
This connector gives a re clocked output of the selected H/SDI input signal.
3.8 Video output connector
This gives a down converted output of HD (Vision only) or a composite PAL/NTSC
video. N.B. This is dependant on the switch selection detailed in section 5.
