AMU2-8HD+/3G 5 Issue 1
AMU2-8HD+/3G AUDIO MONITORING UNIT
1.0 Introduction
This handbook covers the AMU2-8HD+ and AMU2-8HD-3G Audio Monitoring Units.
The AMU2-8HD+/3G are full rack 2RU x 310mm deep Audio Monitoring Units with eight
TSL 53 segment bargraphs.
The following features are standard:
• Four AES/EBU inputs.
• Two HD/SDV auto sensing inputs.
• Re clocked output of input.
• Two Stereo analogue inputs.
• Phase reverse switch.
• Out-of-phase error indication.
• Down converted video or SDV output
• Additive output switch selection.
• Composite output.
• Headphone outputs with LS muting.
• Fixed and variable stereo line outputs of selected pair.
• Four simultaneous line outputs.
• Dolby compatible D and E.
• Metadata display.
• EBU digital, UK PPM and EBU PPM scales available.
• Internal amplifier.
• 1080p50 / 1080p/60 capable (3G units only)
